The International Harvester Company (IHC) has been building its own proprietary truck engines since the introduction of their first truck in 1907. International tended to use proprietary diesel engines. In the 1970s, IHC built the DVT 573 V-8 diesel of 240 and 260 hp (179 and 194 kW) but these were not highly regarded and relatively few were sold. Their DT 466 engine started in 1974 and was very successful.[1]

Harvester

IHC engines[edit]

The first IHC 'Highwheeler' truck had a very simple air-cooledhorizontally opposed two-cylinder engine with a 5-inch (130 mm) stroke and a 5-inch (130 mm) bore, and produced around 18–20 hp (13–15 kW). Displacement was 196 cubic inches (3.2 L).[2] In 1915 a new L-headwater-cooled 201 cubic inches (3.3 L) inline-four engine appeared.[3] While International's own engines underwent constant developments, the pace of truck production in the twenties was such that others' engines (from Waukesha, Buda, and Lycoming for instance) had to be installed in some parts of the range.[4]

International Harvester's first in house six-cylinder engines appeared in some of the 1926 S-series trucks, seemingly a response to market pressures rather than to any particular need for such a layout.[5] In 1928, a new heavy range of trucks (the HS-series) built around a series of engines from Hall-Scott appeared. These engines were used by IHC for some heavy-duty applications until 1935, although their own large engines (525 cu in (8.6 L) FBD and 648 cu in (10.6 L) FEB) had appeared in 1932.[6] The medium-duty 1930 A-series trucks received the all-new 278.7 cu in (4.6 L) FB-3 six-cylinder engine, with overhead valves and seven main bearings. This was complemented by larger versions of the same engine and was built until late 1940 (as the FBB),[7] the line-up being expanded downward by the smaller FA-series (later FAB) in 1933.[8]

The Wisconsin Historical Society has an extensive collection of McCormick-International Harvester data, including serial number lists for engines, tractors, power units, trucks, and milking machines from 1925 to 1971. IH Serial Numbers. Example: 723 For the 1973 model year, the VIN was modified to consist of a 5 character model code, followed by a letter indicating the model year of production, the plant indicator, a production line within the plant indicator, and a 5 digit serial number that started with 10001 each year.

Search • Tracking • Site Map • Cart. Check out this chart to determine the model year of your tractor. Serial Number Tags Drawbar/Hitches Drivetrain Electrical Engine Exhaust/Intake Fuel System Gaskets/Seals/Bearings Gauges Hoses and Clamps Hydraulic System Lights Oil System PTO. It is believed that approximately 40,000 WIN‑13 rifles were produced. In addition, rifles in the 1.6 million serial number range have been observed ranging from number 1,602,XXX through 1,639,XXX. All of this supports the January 1945 date for the serial number range change. Military M1 Rifle (Garand): International Harvester: Covering numbers: 4400000 - 5211254. Please enter a serial number and click the submit button. FARMALL - McCormick - International Harvester IH - CUB. I wonder what year that old Farmall, International Harvester, Cub, Cub Cadet, or McCormick Deering tractor is and how many were made? The beginning Serial Number of each Model for each year it was produced.| eBay!

The HD inline-sixes, later to become the first in International's long running 'Diamond' series, first appeared in the C-30 truck of 1934.[9] Available in three different displacements (see table), they were renamed 'Green Diamond' in late 1940 for the 1941 model year after a number of detail improvements.[7] This year also brought the new 'Blue Diamond' (FAC) and 'Red Diamond' (FBC) engines. A post-war version of the 269 cubic inches (4.4 L) Blue Diamond became the 'Super Blue Diamond' when installed in the post-war medium L-line trucks. The Blue Diamond engine lived on until the early 60's renamed as Black Diamond engines, the BD-282 and BD-308.[10]

International Harvester Gasoline I4 Engines
Engine FamilyCylinder LayoutDisplacement(s)Fuel System TypeYears Produced
'Comanche' 4I4
  • 4-152 (152 cu in (2.5 litres))
  • 4-196 (196 cu in (3.2 litres))
Carburetor1961-1972
International Harvester Gasoline I6 Engines
Engine FamilyCylinder LayoutDisplacement(s)Fuel System TypeYears Produced
HD
Green Diamond
I6
  • HD/GD 175 (174.9 cu in (2.9 L))[11]
  • HD-3/GD 214 (3.5 litres; 213.3 cubic inches (3,495 cc))[12]
  • HD-2/GD 233 (233.9 cu in (3.8 litres))[13]
L-head
Carburetor
1934-1949
FAC[7]
Blue Diamond
I6
  • FAC 241 (241.5 cu in (4.0 litres))
  • BLD 250 (250.56 cu in (4.1 L))[14]
  • FAC260 (259.7 cu in (4.3 litres))
  • BLD269 (269.1 cu in (4.4 litres))
Carburetor1941-1954
Silver Diamond[10]
Black Diamond/BD[15]
BG[16]
I6
  • SD-220 (220.5 cu in (3.6 litres))
  • SD-240/BG-241 (240.3 cu in (3.9 litres))
  • BD-264/BG-265 (264.33 cu in (4.3 L))

The next two are the last versions of the Blue Diamond style engines now named Black Diamond engines.

  • BD-282 (282.54 cu in (4.6 L))
  • BD-308 (308 cu in (5.0 litres))
Carburetor1949-1969
FBC
Red Diamond
I6
  • FBC/RED 318 (318.4 cu in (5.2 litres))
  • FBC/RED 361 (360.8 cu in (5.9 litres))
  • RD 372 (372 cu in (6.1 litres))
  • FBC/RED 401 (400.9 cu in (6.6 litres))
  • RD 406 (406 cu in (6.7 litres))
  • RED 450 then RD 450 (450 cu in (7.4 litres))
  • RD 501 (501 cu in (8.2 litres))
Governed Carburetor1941-1974
International Harvester Gasoline V8 engines
Engine FamilyCylinder LayoutDisplacement(s)Fuel System TypeYears Produced
V/LVV8
  • LV-401 (400.9 cu in (6.6 litres))
  • LV-461 (461 cu in (7.6 litres))

LV-478

  • LV-549 (548.7 cu in (9.0 litres)

Re-engineered engine used in early 70's the V-537. A version of this engine never made it into trucks because of the gas crises of 1973. It was sold for industrial purposes as the V-605.

Governed Carburetor1955-1974
MVV8
  • MV-404 (404 cu in (6.6 litres))
  • MV-446 (446 cu in (7.3 litres))
Carburetor1974-198?
SV
'Comanche'
V8
  • SV-266 (266 cu in (4.4 litres))
  • SV-304 (304 cu in (5.0 litres))
  • SV-345 (345 cu in (5.7 litres))
  • SV-392 (392 cu in (6.4 litres))
Carburetor1959-1985

International Harvester/Navistar engines[edit]

International Harvester/Navistar V6/V8 engines
Engine FamilyCylinder LayoutDisplacement(s)Injection TypeYears Produced
DVV8
  • DV 462 - 7.6 L (460 cu in)
  • DV 550 - 9 L (550 cu in)
  • DV 550B - 9 L (550 cu in)
Direct injection
  • DV 462 - 1966-1988
  • DV 550 - 1966-1988
  • DV 550B - 1966-1988
D-Series
  • D 150
  • D 170
  • D 190
V89 L (550 cu in)Direct Injection1962-early 1988
9.0L V8V89 L (550 cu in)Direct Injection1966-1988
IDI

(International/Ford)

V8
  • 420 cubic inches (6.9 L)
  • 444 cubic inches (7.3 L)
Indirect injection
  • 1983-1987 (6.9L)
  • 1988-1994 (7.3L)
T444E
Original Ford PowerStroke
V8444 cubic inches (7.3 L)Direct injection1994-2004
VT
2nd-generation Ford PowerStroke
  • VT275-V6
  • VT365-V8
  • 275 cubic inches (4.5 L)
  • 365 cubic inches (6.0 L)
Direct injection2003-2010

Navistar DT engines[edit]

Navistar DT engine family
GenerationCylinder LayoutDisplacement(s)Injection typeYears produced
PLN
(Pump Line and Nozzle)
  • DT 360
  • DT 466
Inline-6
  • DT 360 - 360 cubic inches (5.9 L)
  • DT 466 - 466 cubic inches (7.6 L)
Direct Injection1984-late 1995
NGD
(New Generation Diesel)
  • DT408
  • DT466/HT466
  • DT530/HT530
  • DT 408 - 408 cubic inches (6.7 L)
  • DT 466/HT466 - 466 cubic inches (7.6 L)
  • DT 530/HT530 - 530 cubic inches (8.7 L)
1994-1997
HEUI
(Hydraulically actuated

Electronically controlled Unit Injection)

  • DT466/HT466
  • DT530/HT530
  • DT 466/HT466 - 466 cubic inches (7.6 L)
  • DT 530/HT530 - 530 cubic inches (8.7 L)
1994-2004
G2

(Electro-Hydraulic Generation Two)

  • DT 466/HT466
  • DT 570/HT570
  • DT 466/HT466 - 466 cubic inches (7.6 L)
  • DT 570/HT570 - 570 cubic inches (9.3 L)
2004-2007

MaxxForce engines[edit]

Navistar International MaxxForce Engine Family
Engine FamilyCylinder LayoutDisplacement(s)Injection typeYears produced
MaxxForce 5V6275 cubic inches (4.5 L)Direct Injection2007-current
MaxxForce 7
3rd Generation Ford PowerStroke
V86.4L
  • 2007-current (International)
  • 2008-2010 (Ford)
MaxxForce DTInline-6466 cubic inches (7.6 L)2007-current
MaxxForce 9570 cubic inches (9.3 L)
MaxxForce 10570 cubic inches (9.3 L)
MaxxForce 1110.5 L
MaxxForce 1312.4 L
